German Standard Automotive Cable--FHL91X

Model

Magnitudo mm²

Cores

Conductor

Insulation

Range

Maximilianus. DC Resistentia ad XX°C

Conductor Structure

Min. Crassitudo

Min.

Maximilianus.

Nuda Copper

Tinted Cuprum

mm

mm

mm

mm

Ω/km

FHL2X/91X

0.5

1

16/0.20

0.48

2.00

2.30

37.1

38.2

FHL2X/91X

0.75

1

24/0.20

0.48

2.20

2.50

24.7

25.4

FHL2X/91X

1.0

1

32/0.20

0.48

2.40

2.70

18.5

19.1

FHL2X/91X

1.25

1

26/0.25

0.48

2.40

2.95

14.9

15.9

FHL2X/91X

1.5

1

30/0.25

0.48

2.70

3.00

12.7

13

FHL2X/91X

2

1

40/0.25

0.48

3.00

3.30

9.42

9.69

FHL2X/91X

2.5

1

50/0.25

0.56

3.30

3.60

7.6

7.82

FHL2X/91X

3

1

44/0.30

0.56

3.80

4.10

6.15

6.39

FHL2X/91X

4

1

56/0.30

0.64

4.00

4.40

4.71

4.85

FHL2X/91X

5

1

70/0.30

0.64

4.50

4.90

3.94

4.02

FHL2X/91X

6

1

84/0.30

0.64

4.60

5.00

3.14

3.23

FHL2X/91X

8

1

112/0.30

0.64

5.00

5.90

2.38

2.52

FHL2X/91X

10

1

322/0.20

0.80

5.90

6.50

1.82

1.85

FHL2X/91X

12

1

385/0.20

0.80

6.60

7.40

1.52

1.60

FHL2X/91X

16

1

511/0.20

0.80

7.70

8.30

1.16

1.18

FHL2X/91X

20

1

646/0.20

0.88

8.10

9.10

0.955

0.999

FHL2X/91X

25

1

798/0.20

1.04

9.40

10.40

0.743

0.757

FHL2X/91X

30

1

950/0.20

1.04

9.70

10.90

0.647

0.684

FHL2X/91X

35

1

1121/0.20

1.04

9.60

11.60

0.527

0.538

FHL2X/91X

40

1

1273/0.20

1.12

11.20

12.40

0.473

0.500

FHL2X/91X

50

1

1596/0.20

1.20

11.50

13.50

0.368

0.375

FHL2X/91X

60

1

1924/0.20

1.20

13.40

14.60

0.315

0.333

FHL2X/91X

70

1

2220/0.20

1.20

13.50

15.50

0.259

0.264

FHL2X/91X

85

1

2701/0.20

1.28

14.80

16.80

0.219

0.225

FHL2X/91X

95

1

3034/0.20

1.28

16.00

18.00

0.196

0.200

FHL2X/91X

120

1

3811/0.20

1.28

17.70

19.70

0.153

0.156
