German Standard Automotive Cable--FHLR91X (Thin Wall)

Model

Magnitudo mm²

Cores

Conductor

Insulation

Range

Maximilianus. DC Resistentia ad XX°C

Conductor Structure

Min. Crassitudo

Min.

Maximilianus.

Nuda Copper

Tinted Cuprum

Nickel-patella Cuprum

mm

mm

mm

mm

Ω/km

FHL2X/91X

0.35

1

12/0.20

0.20

1.20

1.40

54.4

55.5

56.8

FHL2X/91X

0.5

1

16/0.20

0.22

1.40

1.60

37.1

38.2

38.6

FHL2X/91X

0.75

1

24/0.20

0.24

1.70

1.90

24.7

25.4

25.7

FHL2X/91X

1.0

1

32/0.20

0.24

1.90

2.10

18.5

19.1

19.3

FHL2X/91X

1.25

1

26/0.25

0.24

2.10

2.30

14.9

15.9

16.0

FHL2X/91X

1.5

1

30/0.25

0.24

2.20

2.40

12.7

13.0

13.2

FHL2X/91X

2

1

40/0.25

0.28

2.50

2.80

9.42

9.69

9.82

FHL2X/91X

2.5

1

50/0.25

0.28

2.70

3.00

7.60

7.82

7.92

FHL2X/91X

3

1

44/0.30

0.32

3.10

3.40

6.15

6.39

6.41

FHL2X/91X

4

1

56/0.30

0.32

3.40

3.70

4.71

4.85

4.91

FHL2X/91X

5

1

70/0.30

0.32

3.90

4.20

3.94

4.02

4.11

FHL2X/91X

6

1

84/0.30

0.32

4.00

4.30

3.14

3.23

3.27

FHL2X/91X

8

1

112/0.30

0.32

4.60

5.00

2.38

2.52

2.60

FHL2X/91X

10

1

322/0.20

0.48

5.30

6.00

1.82

1.85

1.90

FHL2X/91X

12

1

385/0.20

0.48

5.80

6.50

1.52

1.60

1.66

FHL2X/91X

16

1

511/0.20

0.52

6.40

7.20

1.16

1.18

1.21

FHL2X/91X

20

1

646/0.20

0.52

7.00

7.80

0.955

0.999

1.03

FHL2X/91X

25

1

798/0.20

0.52

7.90

8.70

0.743

0.757

0.774

FHL2X/91X

30

1

950/0.20

0.64

8.70

9.60

0.647

0.684

0.706

FHL2X/91X

35

1

1121/0.20

0.64

9.40

10.40

0.527

0.538

0.549

FHL2X/91X

40

1

1273/0.20

0.71

10.00

11.10

0.473

0.500

0.516

FHL2X/91X

50

1

1596/0.20

0.71

11.00

12.20

0.368

0.375

0.383

FHL2X/91X

60

1

1924/0.20

0.80

12.00

13.30

0.315

0.333

0.344

FHL2X/91X

70

1

2220/0.20

0.80

13.00

14.40

0.259

0.264

0.270

FHL2X/91X

85

1

2701/0.20

0.90

14.40

15.80

0.219

0.225

0.228

FHL2X/91X

95

1

3034/0.20

0.90

15.30

16.70

0.196

0.200

0.204
