German Standard Automotive Cable--FHL2GBC2G

Name: German Standard Automotive Cable--FHL2GBC2G
Brand: Jiangsu Silver& Tin Thread Hi-temperature Wire and Cables Co., Ltd.

Vestibulum Processus:
Conductor: filum aeneum nudum, filum aeneum stultum
Insulation: Silicone Purgamentum Insulation
Scutum: filum aeris plectere tinned
Involutio: Aluminium-plastic taenia
Jacket: Silicone rubber iaccam
Temperatus dolor:-40°C ~ 200°C
Standard: ISO 19642 Classis F
Ratum Voltage: AC 1000V / DC 1500V
Aliquam Requisita: Obsequium RoHS et SPATIUM
Reference Standard: ISO 19642、LV216

Applications
Alte flexibilis, altis et infimis temperaturis renitens, flamma retardat et tutus. Apta EV saepta summus temperatus et summus currenti connexio alta intentione wiring.

Nunc deme

PRAEC: German Standard Automotive Cable--FLYY

SEQ: German Standard Automotive Cable--FHL2XBC2X

Descriptio
Dic nobis nuntium tuum

Model	Specification	Numerus Cores	Conductor		Insulation			Tin-Platted Copper Braid	Vagina			Maximum DC resistentiam conductor ad XX°C
			Conductor - Conductor Construction	Conductor - Min. Crassitudo (mm)	Diameter exterior	Insulatio Range		Diameter	Mediocris Crassitudo	Vagina Range		Nuda Copper	Tin- cuprea patella	Nickel-patella cuprum
			mm	mm	mm	Min	Max	Max	mm	Max	Min	Ω/km
FHL2X/91X	1.5	1	30/0.25	0.48	2.89	2.7	3	0.13	0.9	4.9	5.3	12.7	13	13.2
FHL2X/91X	2	1	40/0.25	0.48	3.18	3	3.3	0.13	0.9	5.2	5.6	9.42	9.69	9.82
FHL2X/91X	2.5	1	50/0.25	0.56	3.54	3.3	3.6	0.13	1	5.5	6.1	7.6	7.82	7.92
FHL2X/91X	3	1	44/0.30	0.56	3.89	3.8	4.1	0.16	1	6.1	6.7	6.15	6.39	6.41
FHL2X/91X	4	1	56/0.30	0.64	4.39	4	4.4	0.16	1.1	6.6	7.2	4.71	4.85	4.91
FHL2X/91X	5	1	70/0.30	0.64	4.69	4.5	4.9	0.16	1.1	7.1	7.7	3.94	4.02	4.11
FHL2X/91X	6	1	84/0.30	0.64	4.97	4.6	5	0.16	1.1	7.2	7.8	3.14	3.23	3.27
FHL2X/91X	8	1	112/0.30	0.8	6.02	5	5.9	0.19	1.2	8.5	9.1	2.38	2.52	2.6
FHL2X/91X	10	1	322/0.20	0.8	6.46	5.9	6.5	0.19	1.2	9.1	9.7	1.82	1.85	1.9
FHL2X/91X	12	1	385/0.20	0.8	7.12	6.6	7.4	0.19	1.3	10.2	10.8	1.52	1.6	1.66
FHL2X/91X	16	1	511/0.20	0.88	8.04	7.7	8.3	0.19	1.3	11.1	11.7	1.16	1.18	1.21
FHL2X/91X	20	1	646/0.20	1.04	9.16	8.1	9.1	0.19	1.4	12.1	12.7	0.955	0.999	1.03
FHL2X/91X	25	1	798/0.20	1.04	9.85	9.4	10.4	0.21	1.4	13.4	14	0.743	0.757	0.774
FHL2X/91X	30	1	950/0.20	1.04	10.5	9.7	10.9	0.21	1.5	14.1	14.7	0.647	0.684	0.706
FHL2X/91X	35	1	1121/0.20	1.12	11.34	9.6	11.6	0.21	1.5	14.8	15.4	0.527	0.538	0.549
FHL2X/91X	40	1	1273/0.20	1.2	12.09	11.2	12.4	0.21	1.5	15.6	16.2	0.473	0.5	0.516
FHL2X/91X	50	1	1596/0.20	1.2	13.15	11.5	13.5	0.21	1.6	16.7	17.5	0.368	0.375	0.383
FHL2X/91X	60	1	1924/0.20	1.2	14.06	13.4	14.6	0.21	1.6	17.8	18.6	0.315	0.333	0.344
FHL2X/91X	70	1	2220/0.20	1.28	15.08	13.5	15.5	0.21	1.6	18.9	19.7	0.259	0.264	0.27
FHL2X/91X	85	1	2701/0.20	1.28	16.41	14.8	16.8	0.26	1.7	20.4	21.2	0.219	0.225	0.228
FHL2X/91X	95	1	3034/0.20	1.28	17.17	16	18	0.26	1.7	21.6	22.4	0.196	0.2	0.204
FHL2X/91X	120	1	3811/0.20	1.28	19.06	17.7	19.7	0.26	1.7	23.3	24.1	0.153	0.156	0.159
